PERKO 1168 - Manual (Page 2)

NAVIGATION LIGHT CERTIFICATE OF COMPLIANCE
This navigation light has been tested and classified by UNDERWRITERS’
LABORATORIES, INC. (U.L.) in accordance with the ‘72 COLREGS and the
U.S. INLAND NAVIGATION RULES ACT OF 1980. When properly installed,
and fitted with the correct lamp, this light is approved by the U.S. Coast
Guard for use aboard U.S. Coast Guard inspected vessels. This certification
is also accepted by other inspecting authorities. An identification plate
attached to the light provides lamp replacement and official certification
information.
Upon installation, record information below from the identification plate, as
applicable to the class of vessel on which the light is to be fitted.
Type of Light ___________________________________________________
(Masthead, Stern, Etc)
Cat. No. ________________________________________________________
(Cat. No. 1164GE0PLB, 1165E00PLB, Etc.)
D.O.M. No. _____________________________________________________
(Die Stamped)
Vessel Length ___________________________________________________
Replacement Lamp ______________________________________________
(Cat No. of lamp)
Date of Installation ______________________________________________
Vessel Identification _____________________________________________
10/04
PERKO, INC.
16490 N.W. 13th Avenue
Miami, FL 33169-5707
www.perko.com
INSTALLATION INSTRUCTIONS
FOR CAT. NOS. 1164-1168 “E” SERIES
DOUBLE LENS NAVIGATION LIGHTS
The above lights are designed for use on vessels over 20 meters (65.6 ft.) in length, operating on a 120 volt electri-
cal system. In order to comply with the ‘72 COLREGS and the U.S. Inland Rules, the following must be adhered to:
MOUNTING INFORMATION
Read all instructions before proceeding.
1). These instructions describe the installation of the lights after the proper mounting location has been
determined. For proper light selection, positioning and configuration, refer to the ‘72 COLREGS* U.S. Inland
Navigation Rules* and/or other governing requirements applicable to the type and class of vessel.
2). These lights are designed to be mounted on a horizontal surface.
3). All electrical supply connections must be in accordance with applicable marine electrical standards and
regulations and accomplished by a qualified marine electrician.
4). Proper lamp(s) must be selected in accordance with the identification plate mounted on the light.
5). Record information from the identification plate onto the “Navigation Light Certificate Of Compliance’ and store
with the vessel’s documents.
6). If this installation is a retro-fit of older lights, the mounting arrangement has been changed from the previous
style so that the light fixture is now bolted directly to the mounting surface. However, the new bolt holes match
the location of the bolt holes in the old style base plate.
7). Align light by making sure that a reference line drawn through the fore-aft marks on the light is parallel to the
fore-aft centerline of the vessel.
8). Using the base as a template, mark the mounting surface and drill for 3/8 inch bolts.
9). After bolting in place, recheck alignment.
10). To access lamp in the lower compartment:
(a). Make sure light is de-energized.
(b). Remove cover on top of light.
(c). Loosen the two diagonal screws adjacent to the upper
compartment socket.
(d). Pull socket assembly straight up.
(a). After inserting lamp, reverse procedure to re-install.
Note that the socket assembly electrical connectors are
polarized and will allow insertion one way only.
*The above referenced regulations can be obtained from:
U.S. Coast Guard
Washington, D.C. 20593
(or your local C.G. office)
PERKO, INC.
16490 N.W. 13th Avenue
Miami, FL 33169-5707
1164INS1 www.perko.com
