SECTION 1 - INSTALLATION
Installation of the Access Plus Telephone Entry and Access Control System involves the installation
of the hardware and the wiring of these components.
If used to control a vehicular gate with an automatic gate operator, the telephone
entry system must be mounted a minimum of six (6) feet away from the gate and
gate operator, or in such a way that a person cannot operate the entry system
and/or touch the gate or gate operator at the same time.
1.1
Mount the Access Plus Unit
Surface mount units can be mounted directly to a wall or pilaster or post mounted using a DoorKing
mounting post (there are several different styles available). Flush mount units are designed to be
mounted into a pilaster, wall or kiosk. In any case, be sure that the unit is securely mounted and is
not subject to continuous vibration from closing doors or gates.
1. Open the cabinet and carefully disconnect the front panel terminal connector and the
keypad connector. The front panel terminal connector is located in the lower right hand
corner. The entire connector will come off the board by gently pulling it straight out.
2. Remove four (4) 6-32 a 1/2 round head screws from each corner of the control board.
3. Remove the control board from the housing. CAUTION: The control board contains static
sensitive components. Discharge any static electricity from your hands by touching a
proper ground device before removing the control board.
4. Mount the housing assembly. Make any conduit connections at this time. Be sure that the
mounting screws do not protrude into the cabinet where they could cause a short.
5. Route wiring into the housing assembly at this time. DO NOT APPLY POWER.
6. Clean out the back box. Be sure that all dirt, metal or wood debris is removed from the
back box.
7. Remove the main terminal wiring connector from the control board by gently pulling it
straight up. This will make wiring to the main terminal easier.
8. Install the control board into the back box. Secure the control board with the four (4) 6-32
x 1/2 screws removed in step 2. CAUTION: The control board contains static sensitive
components. Discharge any static electricity from your hands by touching a proper
ground device before installing the control board.
9. Plug the front panel connector onto the control board pins in the lower right hand corner.
The red wire goes to the left.1
10. Plug the keypad connector onto the circuit board plug. The cable points down.
11. After pre-wiring the main terminal control board connector (see wiring instructions),
carefully re-install it onto the control board main terminal pins.
1810-162-J-1-12 Page 9
