1.2 Dimensions
Surface Mount 1810 Access Plus
DOORKING, INC., INGLEWOOD, CA 90301
Date: Dwg. No.
Surface Mount Case and Mounting Hole
Dimensions
Rev.
Title:
10/09 A M1810-AP-1
2.625
1.625
.875 DIA
10.125
.25 DIA
13
.0
10.
87
5
11.25
2.625
.875 DIA
8.75
4.75
Standard Surface Mount Housing Case and Mounting
Hole Dimensions
1
3.25
9.0
Page 10 1810-162-J-1-12
