1.9.3 Modem Connections
Access Plus unit’s have a built-in modem that can be used to connect to a PC. Before programming
can be attempted, you need to install the Access Plus Account Manager programming software on
the computer you want to use for this purpose. The computer must have a modem installed or an
external modem connected to it. Follow the instructions in the software help guide for setup
information.
Modem Connection – Auto-Dialer Configuration Only
