1.7 1816 Access Plus Detail Wiring
1881 Decoder Board
1 2 3 4 5 6 7 8 9 10
DOORKING, INC., INGLEWOOD, CA 90301
Date: Dwg. No. Rev.
Title:
1/12
C
M1810-AP-4-C
Access Plus System Intercom Wiring
Decoder Board Wiring
Access Plus
System
2 Decoder board is located in the 1816 Access Plus cabinet.
2
Use only twisted pair telephone wire that is rated for direct underground burial.
DO NOT use wire that is intended for indoor applications . Recommend
Cat5e Gel Filled (flooded) UV Resistant Direct Burial Cable in conduit. DO
NOT run telephone wires and high voltage wires in the same conduit .
Check the phone wire chart for wire size / distance.
1
1 1
3
Be sure to properly ground all devices. Minimum 12 AWG wire. Surge devices
must have a ground point within 3-ft of the device.
3
1
Phone Line Wire Size
Wire Size Max Distance (Ft)
24 AWG
22 AWG
800
1600
1
ON
SW1 MODEM / TCP ENB
1
2
3
4
5
6
7
8
1
5
2
3
4
6
8
9
7
12
13
14
15
10
11
17
16
18
Mic
Vol
Master
Code
1 2 3 4 5 6 7 8 9 10 11
Speaker
Vol
Keypad
1810-162-J-1-12 Page 23
