Blade / Engine Speed (RPM) Chart
Model CC2500 Concrete Saw
_____________________________________________________________
CAUTION: Do not exceed Bladeshaft speed (RPM) shown for each blade size. Excessive
Blade Speed could result in blade breakage and serious personal injury.
Gasoline Engine Speeds Electric Motor Speeds
Blade Size Bladeshaft Engine Blade Size Bladeshaft Motor
No Load RPM Sheave Size No Load RPM Sheave Size No Load RPM Sheave Size No Load RPM Sheave Size
14” 2,625 4.12” 3,600 3.00 14” 2,625 4.12” 3,600 3.00
18” 2,625 4.12” 3,600 3.00 18” 2,625 4.12” 3,600 3.00
20” 2,625 4.12” 3,600 3.00 20” 2,625 4.12” 3,600 3.00
24” 2,025 4.75” 3,200 3.00 24” 2,275 4.75” 3,600 3.00
26” 2,025 4.75” 3,200 3.00 26” 2,275 4.75” 3,600 3.00
CAUTION:
When changing blade size, use chart shown below for selecting items
that must be changed.
BLADE
SIZE
MAX DEPTH
OF CUT
MODEL CC2500 14” 20” 26”
14” 4-3/8” Blade Guard Assembly 6010950 6010952 6010954
18” 6-3/8”
Bladeshaft Sheave 6047947 6047947 6047948
20” 7-3/8” (Sheave Size) (4.12”) (4.12”) (4.75”)
24” 9-3/8”
26” 10-3/8”
52
