Diamond Products CC2500 (Gas) User Manual
Page 25
BOTH ARE AVAILABLE SEPARATELY.
INCLUDES THE IGNITION SWITCH ASSEMBLY
6040958
AND THE ENGINE TO IGNITION SWITCH HARNESS ASSEMBLY
6049059
6049057
20.5 HP Honda Engine Assembly 6047704
ITEM
PART NO.
QTY.
DESCRIPTION
1
2600642
1
Engine, 20.5 HP Honda (GX660)
2
2703139
1
Muffler Assembly, High Mount, Left
3
2703556
1
Air Cleaner Assembly
2
2900014
4
Flat Washer, 3/8" SAE
5
2900317
4
Cap Screw, Hex Hd., M10-1.5 x 45mm
6
2900304
4
Lock Nut, M10-1.5 Nylon Insert
7
6047977
1
Key, 1/4" Sq. x 3"
8
2500029
1
Taper Bushing, 1-1/8" with Set Screws
9
2500817
1
Sheave, 3.00-3V-4 Groove
10
6048195
1
Pulley, 1-1/8" Bore
11
2500849
1
V-Belt, 4L-500
12
2500792
4
V-Belt, 3VX400
13
2900036
2
Set Screw, Soc. Hd., 5/16-18 x 1/4"
14
2701670
1
Rectifier Assembly
15
2900009
2
Flat Washer, 1/4" SAE
16
2900008
2
Cap Screw, Hex Hd., 1/4-20 x 1"
17
2900010
2
Lock Nut, 1/4-20 Nylon
18
6047218
1
Vent Hose Assy., 3/8 x 40"
18.1
3200055
1
3/8" ID Hydraulic Hose
18.2
3200390
2
Hose Clamp #6
19
6048236
1
Oil Drain Hose Assembly
19.1
3200462
1
Fitting, M20 x 1.5 to 5/8" M. JIC
19.2
3200440
1
Fitting. 5/8" F. to 1/2" M. JIC
19.3
3200181
1
Fitting, 1/2" F. JIC to 1/2" Pushlok
19.4
3200163
1
Fitting, 1/2" F. Pipe to 1/2" Push Lock
19.5
3200160
1
Plug, 1/2-14 NPT
19.6
6048264
1
Hose, 1/2" I.D. x 8.25"
20
6049059
1
Wire Harness Assembly, Honda
25
