Diamond Products CC2500 (Gas) - Manual (Page 13)

Screw Feed Assembly
#6047702
ITEM PART NO. QTY. DESCRIPTION
1 6047929 1 Adjustment Screw
2 6047927 1 Adjustment Shaft
3 2900354 1 Clevis Pin, 1/2" x 1-3/4"
4 2900276 1 Hairpin Cotter, 1/8" x 1/2" to 3/4"
5 2900062 1 Grease Fitting, 1/8" NPT
6 2500807 1 Bearing, 5/8", Two Bolt Flange
7 6047931 1 Spacer Tube 7/8 x 1/2
8 2900311 2 Cap Screw, Hex Hd., M6 x 25mm
9 2900009 4 Flat Washer, 1/4" SAE
10 2900302 2 Lock Nut, M6 Nylon
11 2500800 1 Handwheel, 8" x 5/8"
12 2900355 1 Lock Nut, 5/8-18, Flex Top
13 6047216 1 Bracket, Handwheel Lock
14 2400138 1 Indexing Plunger, 1/2-13 UNC
15 2900129 1 Jam Nut, 1/2-13
16 2900309 4 Cap Screw, Hex Hd., M5 x 20mm
17 2900016 4 Flat Washer, #10 USS
18 2900301 4 Lock Nut, M5 Nylon
13
