BOTH ARE AVAILABLE SEPARATELY.
INCLUDES THE IGNITION SWITCH ASSEMBLY
6040958
AND THE ENGINE TO IGNITION SWITCH HARNESS ASSEMBLY
6049059
6049057
20.8 HP Honda Engine Assembly 6047705
ITEM
PART NO.
QTY.
DESCRIPTION
1
2600644
1
Engine, 20.8 HP Honda (GX630)
2
2703139
1
Muffler Assembly, High Mount, Left
3
2703556
1
Air Cleaner Assembly
5
2900317
4
Cap Screw, Hex Hd., M10-1.5 x 45mm
6
2900014
4
Flat Washer, 3/8" SAE
7
2900304
4
Lock Nut, M10-1.5 Nylon Insert
8
6047977
1
Key, 1/4" Sq. x 3"
9
6048195
1
Pulley, 1-1/8" Bore
10
2900036
2
Set Screw, Soc. Hd., 5/16-18 x 1/4"
11
2500029
1
Taper Bushing, 1-1/8" with Set Screws
12
2500817
1
Sheave, 3.00-3V-4 Groove
13
2500792
4
V-Belt, 3VX400
14
2500849
1
V-Belt, 4L-500
15
2900009
2
Flat Washer, 1/4" SAE
16
2900008
2
Cap Screw, Hex Hd., 1/4-20 x 1"
17
2900010
2
Lock Nut, 1/4-20 Nylon
18
2701670
1
Rectifier Assembly
19
6048236
1
Oil Drain Hose Assembly
19.1
3200462
1
Fitting, M20 x 1.5 to 5/8" M. JIC
19.2
3200440
1
Fitting. 5/8" F. to 1/2" M. JIC
19.3
3200181
1
Fitting, 1/2" F. JIC to 1/2" Pushlok
19.4
6048264
1
Hose, 1/2" I.D. x 8.25"
19.5
3200163
1
Fitting, 1/2" F. Pipe to 1/2" Push Lock
19.6
3200160
1
Plug, 1/2-14 NPT
20
6047218
1
Vent Hose Assy., 3/8 x 40"
20.1
3200055
1
3/8" ID Hydraulic Hose
20.2
3200390
2
Hose Clamp #6
28
6049059
1
Wire Harness Assembly, Honda
