Diamond Products CC2500 (Gas) User Manual
Page 27
BOTH ARE AVAILABLE SEPARATELY.
INCLUDES THE IGNITION SWITCH ASSEMBLY
6040958
AND THE ENGINE TO IGNITION SWITCH HARNESS ASSEMBLY
6049059
6049057
22.2 HP Honda Engine Assembly 6047715
ITEM
PART NO.
QTY.
DESCRIPTION
1
2601705
1
Honda Engine, 22.2 HP Honda (GX690)
2
2703139
1
Muffler Assembly, High Mount, Left
3
2703556
1
Air Cleaner Assembly
4
2900317
4
Cap Screw, Hex Hd., M10-1.5 x 45mm
5
2900014
4
Flat Washer, 3/8" SAE
6
2900304
4
Lock Nut, M10-1.5 Nylon Insert
7
6047977
1
Key, 1/4" Sq. x 3"
8
6048195
1
Pulley, 1-1/8" Bore
9
2900036
2
Set Screw, Soc. Hd., 5/16-18 x 1/4"
10
2500029
1
Taper Bushing, 1-1/8" with Set Screws
11
2500817
1
Sheave, 3.00-3V-4 Groove
12
2500792
4
V-Belt, 3VX400
13
2500849
1
V-Belt, 4L-500
14
2900009
2
Flat Washer, 1/4" SAE
15
2900008
2
Cap Screw, Hex Hd., 1/4-20 x 1"
16
2900010
2
Lock Nut, 1/4-20 Nylon
17
2701670
1
Rectifier Assembly
18
6048236
1
Oil Drain Hose Assembly
18.1
3200462
1
Fitting, M20 x 1.5 to 5/8" M. JIC
18.2
3200440
1
Fitting. 5/8" F. to 1/2" M. JIC
18.3
3200181
1
Fitting, 1/2" F. JIC to 1/2" Pushlok
18.4
3200163
1
Fitting, 1/2" F. Pipe to 1/2" Push Lock
18.5
3200160
1
Plug, 1/2-14 NPT
18.6
6048264
1
Hose, 1/2" I.D. x 8.25"
19
6047218
1
Vent Hose Assy., 3/8 x 40"
19.1
3200055
1
3/8" ID Hydraulic Hose
19.2
3200390
2
Hose Clamp #6
20
6049059
1
Wire Harness Assembly, Honda
27
