Diamond Products CC2500 (Gas) User Manual
Page 19
Transmission Assembly #6047962
ITEM
PART NO.
QTY.
DESCRIPTION
1
6047923
1
Transmission Platform Weldment
2
2600015
1
Eaton 6 Transmission
3
2900319
4
Cap Screw, Hex Hd., M10-1.5 x 80mm
4
2900014
13
Flat Washer, 3/8" SAE
5
2900304
13
Lock Nut, M10-1.5 Nylon Insert
6
2500017
1
SProcket, 12 Teeth W/ 1/4 Setscrew
7
2900068
2
Woodruff Key #404, 1/8" W x 1/2" Dia.
8
6047924
1
Transmission Pivot Support
9
2900333
2
Cap Screw, Hex Hd., M10-1.5 x 25mm
10
2900330
2
Cap Screw, Hex Hd., M12-1.75 x 30mm
11
2900058
4
1/2 FLAT WASHER
12
2900327
2
Lock Nut, M12-1.75 Nylon Insert
13
6010080
1
Transmission Jackshaft 15T
14
6048229
1
Key, 3/16" Sq. x 1-1/4"
15
2500011
2
Flange Mt. Bearing 3/4"
16
2900223
5
Cap Screw, Hex Hd., M10-1.5 x 30mm
17
2900061
1
Grease Fitting, 1/4-28 x 90 Degree
18
2900184
1
Grease Fitting, 1/4" NPT x 45 degree
19
2500018
1
Sprocket, 48 Teeth w/ Setscrews
20
2900101
4
Set Screw, Soc. Hd., 1/4-20 x 3/8"
21
6048232
1
Chain, #35 x 63 Pitch
22
2500780
1
Spring, 1" Dia. x 6"
23
6048057
1
Engagement Lever
24
2400007
1
Knob, 1/2-20 x 1-3/8" Dia.
25
2900277
1
Clevis Pin, 1/2" Dia. x 1-1/2"
26
2900276
1
Hairpin Cotter, 1/8" x 1/2" to 3/4"
27
2900315
1
Cap Screw, Hex Hd., M10-1.5 x 35mm
28
6047925
2
Linkage
29
2500805
1
Quadco Speed Control
30
2900310
6
Cap Screw, Hex Hd., M6-1.0 x 20mm
31
2900009
8
Flat Washer, 1/4" SAE
32
2900302
6
Lock Nut, M6-1.0 Nylon Insert
33
2500806
1
Speed Control Cable
34
2900188
2
Hex Nut, #10-32
35
2500791
1
Rod End, #10-32 Female
36
2900015
1
Machine Screw, Hex Hd., #10-24 x 3/4"
37
2900017
1
Lock Nut, #10-24 Nylon
38
6047926
1
Shift Lever
39
2900018
1
Lock Nut, 3/8-16 Nylon
40
6047943
1
Cable Control Bracket
41
2500818
1
Clamp, 3/16" Cable
42
2900010
2
Lock Nut, 1/4-20 Nylon
43
2500016
1
Pulley, 6"
44
6048085
1
Idler Arm
45
2900317
1
Cap Screw, Hex Hd., M10-1.5 x 45mm
46
2900321
2
Lock Washer, M10 Split
47
2900325
2
Hex Nut, M10-1.5
48
2500074
1
Idler Pulley 3"
49
2900337
1
Cap Screw, Hex Hd., M10-1.5 x 50mm, Full Thd.
50
2500070
1
Spring, Extension, 3/4 Dia x 4
51
2900055
1
Cotter Pin, 3/16" x 1"
52
2900407
2
Cap Screw, Hex Hd., 7/16-14 x 1"
53
2900045
2
Lock Nut, 7/16-14 Nylon
