29
4
2900014
Flat Washer, 3/8" SAE
#6047997
Hydraulic Power Raise/Lower Assembly
#6047969
Rocker Switch Assembly
30
2900006
4
Lock Washer, 3/8" Split
31
2900314
4
Cap Screw, Hex Hd., M10-1.5 x 20mm
32
2900311
2
Cap Screw, Hex Hd., M6-1.0 x 25mm
33
6047969
1
Rocker Switch Assembly
ITEM PART
NO.
QTY.
DESCRIPTION
1
2900009
2
Flat Washer, 1/4" SAE
2
6047965
1
Actuator Clevis
3
2900302
2
Lock Nut, M6-1.0 Nylon Insert
4
3200067
1
Breather Vent, 1/4" NPT
5
2900276
2
Hairpin Cotter, 1/8" x 1/2" to 3/4"
6
2900393
1
Clevis Pin, 1/2 x 1-3/4", Zinc Plated
7
3200312
1
Elbow, 1/4" Male Pipe
8
3200056
1
Flow Control Valve, 1/4" NPT
9
3200057
1
Elbow, 1/4" M. Pipe to 1/4" M. JIC
10
2501588
1
Hydraulic Cylinder
11
6047966
1
Cable Connecting Arm
12
2900109
1
Jam Nut, 1/2-20
13
2900354
1
Clevis Pin, 1/2" x 1-3/4"
14
6010248
1
Hose Assembly, 20" Long
15
6048092
1
Battery Cable Assy., Black
16
2800198
1
Battery Boot, Small (Black)
17
2500931
1
Rod End, 1/2-20 Male
18
6047990
1
Battery Cable Assy., Red
19
2900019
3
Cap Screw, Hex Hd., 5/16-18 x 3/4"
20
2900031
4
Lock Washer, 5/16" Split
21
2900022
4
Flat Washer, 5/16" SAE
22
2600540
1
Electro/Hydraulic Pump Unit
23
3201873
1
Elbow, 5/16" O-Ring to 1/4" M. JIC
24
2800197
1
Battery Boot, Small (Red)
25
6047986
1
Pump Guard
26
2900329
1
Cap Screw, Hex Hd., M8-1.25 x 20mm
27
2900611
1
Cap Screw, Flat Hd., M8-1.25 x 20mm
28
6047987
1
Frame Lift Weldment
ITEM PART
NO.
QTY.
DESCRIPTION
34
2800260
1
Rocker Mount Panel
35
2800261
1
Rocker Panel Gasket
36
2800258
1
Rocker Switch Body
37
2800259
1
Rocker Switch Actuator
