Classic Pro Gun Manual
Rev. 08/2012 Page | 19
Gun Disassembly:
WARNING: To prevent injury, be sure all air is disconnected from the gun and
that all pressure has been relieved before attempting to remove trigger guard.
Note: The bolt that secures the trigger guard to the air cylinder also serves as a
plug for the end cap. Removing this bolt can result in injury from escaping
pressurized air if air pressure is not relieved.
1. Check to be sure all air is disconnected from the gun
2.
Be sure all pressure is relieved from the gun.
3.
Disconnect the trigger guard by using a wrench to remove the nut securing the
top of the trigger guard to the end cap on the gun’s actuating cylinder.
Disassemble Gun into Modules
Note: If your Pro Gun™ is used for chopping, perform the two steps, A and B:
A. Detach the chopper assembly by removing the air tube that connects the
chopper to the gun handle.
B. Remove the hex cap screw securing the chopper to the top of the gun block. Use
caution not to lose the eccentric stud in the chopper mount.
1. Remove the four screws that secure the gun block to the actuator. Set gun block
a side for now
2.
Remove the two mounting screws which secure the handle to the actuator.
3.
You have now disassembled the gun into modules. Next you will disassemble,
clean, and reassemble each module.
