Laurel Electronics LAUREATE SERIES COUNTER_TIMER User Manual
Page 15
0
Reset total
1
Display stored total
0
Blank leading zeros
1
Display leading zeros
0
Scale1 using scale and
offset
1
Scale1 using coordinates
of 2 points
0
Scale2 using scale and
offset
1
Scale2 using coordinates
of 2 points
0
A: Meter reset
B: Function reset
1
A: Meter reset B: Hold
2
A: Meter reset
B: Peak display
3
A: Meter reset
B: External gate
4
A: Funct. reset B: Hold
5
A: Function reset
B: Peak display
6
A:Funct reset B:Ext gate
7
A: Hold B: Peak display
VOLTAGE-TO-FREQUENCY CONVERTER
A OnLy
calculates rate for
input A (I1)
bAtCH
calculates rate
(I3), total (I1), grand total for
batching (I2), input A
A Atot
calculates rate (I1)
and total for input A (I2)
Atot A
calculates rate for
input A (I2) and total for input
A (I1)
1 / A
calculates the
inverse of rate for input A (I1)
InPut
Input signal type
Note:
(I1), (I2), and (I3) are display
items 1, 2, and 3. The value
that is displayed may be se-
lected via front panel
pushbutton.
UF4 20
4 to 20ma signal input
UF 0 1
0 to 1ma signal input
UF0 10
0 to 10V signal input
Basic counter:
A Only
Extended counter:
All items shown
SEtuP
Meter Setup
00000
Display total at power on
00000
Display of leading zeros
00000
Method of scaling (Scale1)
00000
Method of scaling (Scale2)
00000
Rear connector inputs A & B
Low input = true
VALUE SELECT KEY
MENU KEY
DIGIT SELECT KEY
-13-
