TECHNICAL SUPPORT 1 800 908 0884 32
Gate does not run – Motor Sensor indicator comes ON
TROUBLESHOOTING TROUBLESHOOTING
Check all motor connections to
be fully engaged. Refer to page
18 and 19. Ensure that the motor
connections are:
a) Properly connected;
b) Tight enough and;
c) Match color code.
Refer to page 13. Check that all motor cable
connections, junctions and
extensions are properly
connected and color-coded.
Refer to page 13.
Check the 15 Amp fuse in the
control board
Gate does not run – Motor Sensor indicator is OFF
Check all motor connections to
be fully engaged. Refer to 1, 15
and 19. Check that the stop command
is not active. Refer to page 8
and 25.
Gate does not run – Power failure
Check the 15 Amp battery fuse.
Refer to page 16. Check the battery connections
and cables. Check the voltage of the
battery.
Gate does not run – Obstruction sensor ON and audio alarm is SOUNDING
Ensure that the gate path is
clear of obstructions. Note: To stop the audio alarm,
use the stop command. Refer
to page 8 and 25.
Gate runs, stops and reverse momentarily – Obstruction sensor ON and audio alarm OFF
Ensure that the gate path is
clear of obstructions. Check for proper functionality
and lubrication of the gate and
hardware (hinges and the like). Adjust the trim pot of the
obstruction sensor. Refer to
page 26.
Check that the UL command
(photo beam and/or edge
sensor) is not active. Refer to
page 6, 7 and 22. Check that the vehicular loop
detectors are working properly.
Refer to page 20, 21 and 22. Check that the radio command
is not active. Refer to page 23.
Ensure that you external acces-
sories are working properly. Check the 4 Amps fuse in the
control board Ensure that you power cables are
adequate in voltage and properly
connected. Refer to page 17.
