Connect the wires from the motor unit to
the terminal block mounted next to the
control board. Match wire colors to the
terminal block.
Single Unit Connections
ELECTRICAL INSTALLATION – SINGLE UNIT ELECTRICAL INSTALLATION – SINGLE UNIT
Match
Colors
Connect the wire harness to the “OPEN
RIGHT” connector if the gate opens towards
the right side. Connect the wire harness to
the “OPEN LEFT” connector if the gate opens
towards the left side.
