9050-065-M-3-11 29
NC
NO
4702-010
12
11
10
9
8
7
6
5
4
3
2
1
5.2 Control Wiring for Single/Primary Operator
Key Switch
Stand-Alone
Keypad
Stand-Alone
Card Reader
Telephone
Entry
Fire Box
Switch 2:
OFF - Input will reverse a
closing gate to full open
position and prevent gate
from closing.
ON - Input will reverse a
closing gate to full open
position, reset and hold
timer. When gate is clear, timer will
time-out and close gate.
Functions ONLY during closing cycle.
This CANNOT be used as UL 325
secondary entrapment protection.
Note: All stand-alone, telephone entry and photo
sensor devices must use a separate power source.
Com
Com
Com
Relay
24 Volt, 250 mamp. Max.
3-Wire Radio
Receiver
Relay Com
Relay N.O.
N.O.
N.O.
24 Volt Power Com
24 Volt Power
4-Wire
Radio
Receiver
Important: Controls must be far enough from the gate so that the user is prevented from coming in contact with the gate while
operating the controls. Outdoor or easily accessible controls should have a security feature to prevent unauthorized use.
1 ON
2
3
4
5
6
7
8
“Optional” REVERSE GATE
for Closing Direction
Photo Sensors
W ARNING
MOVIN G G AT E CAN CAU SE
Op era te g ate on ly w hen ga te a rea is i n s igh t
and fre e o f pe ople an d o bstr ucti ons .
Do no t all ow ch ildr en t o p lay in g ate are a
or o per ate ga te. Do no t sta nd i n g ate pa th o r w alk thro ugh
path w hile ga te is m ovin g. Rea d o wn er’s m anu al a nd s afe ty in stru ctio ns.
SERI OUS INJ URY OR DE ATH
CLA SS
CER TIF IED TO CA N/C SA C2 2.2 NO . 2 47
CO NF OR MS TO AN SI/U L-3 25 VEH ICU LA R G ATE OP ER ATO R HP
533 82 MO DE L SER IAL VO LTS
PH AS E
AM PS
60 H z
MA X G ATE LO AD Door King, Inc ., Inglew ood, CA
