background image

6400-065-E-05-07

24 6400

installation

guide

NOTE:
When servicing or performing any maintenance to the gate operator always check the inherent
reversing system and secondary (external) reversing devices (loops, photo eyes, etc). If the inherent
reversing system cannot be made operable, remove the gate operator from service until the cause of
the malfunction is identifi ed and corrected. Keeping the gate operator in service when the inherent
reversing system is malfunctioning creates a hazardous condition, which can result in serious injury or
death if entrapped in the gate.

Component

Maintenance Description

3

6

12

Alarm

Activate the primary (inherent) reverse system by blocking the gate
with a solid object. When the gate reverses, block the gate in the
opposite direction prior to the limit being reached. The entrapment
alarm should activate. Press the reset button to silence the alarm.

Batteries

Check the batteries for any leakage or loose connections. Batteries
should be replaced every two years.

Fire Dept.

Check emergency vehicle access device for proper operation.

Gate

Inspect for damage. Check gate hinges for wear and grease if
necessary.

Primary

Reverse

System

Check that the gate reverses on contact with an object in both the
opening and closing cycles. Adjust the clutch if necessary.

Loop(s)

Check vehicular reverse and shadow loops for proper operation.

Release

Check manual release for proper operation.

Secondary

Reverse

Device

Check secondary (external) reverse device(s) stop or reverse the gate
when activated.

Complete

Complete check of gate and gate operating system.

month

month

month

technical information / maintenance schedule

5

The gate operator should be inspected and serviced by a qualifi ed
technician anytime a malfunction is observed or suspected. High

cycle usage may require more frequent service checks (see maintenance
schedule). When servicing the gate operator, be sure that the 24 VAC input
power, batteries are disconnected.
