4.4 Accessory Items
The following accessory items are available for the model 6002 swing gate operator.
Photo Cell - Non-contact (photo-cells) sensors for use as a secondary entrapment protection device.
EMX Industries, Inc. Model IRB-325
MMTC, Inc. Model E3K-R10K4-NR
Loop Detector - Detectors plug directly into ports on circuit board simplifying wiring.
P/N 9410-010 - Single channel detector
P/N 9409-010 – Two-channel detector
Magnetic Lock - Magnetic Gate Lock Kit provides an excellent means to secure swing gates and is a fail-safe device allowing
emergency vehicle access upon power outage.
P/N 1216-080 and P/N 1216-081
Interconnect Cable - Interconnect wire cable contains all the necessary wires to interconnect primary / secondary operators.
Cable length 30 feet. P/N 2600-755 Cable length 40 feet. P/N 2600-756 Cable length 50 feet. P/N 2600-757
Time Clock - 7 day and 365 day time clocks can be used to automatically open gate at pre-set time and days. Compact clock fits
inside the operator.
P/N 2600-791 - 7 day clock
P/N 2600-795 - 365 day clock
Torsion Rods - Torsion rod assembly is used on uphill swing gates for counter balance.
P/N 1203-084
Hinges - Heavy-duty ball bearing hinges provide easy swing gate operation.
P/N 1200-009, P/N 1200-019, P/N 1200-039. Two (2) required.
Surge Devices - High and low voltage surge suppressors help prevent circuit board failure caused by lightning strikes and
power surges.
P/N 1876-010 - High Voltage
P/N 1878-010 - Low Voltage
Gate Scale - Use to test torque required to move gate. P/N 2600-225
Speed Bumps - Prefabricated six-foot speed bump reduces traffic speed through gate system. P/N 1610-150
Batteries - 12 Volt 3 Amp Hour. P/N 1801-009. Two (2) required.
Fuse - 5 Amp. P/N 4601-058.
4.3 Diagnostics Check
Have the following diagnostic tools available: VOM meter with minimum voltage memory or min-max range to check voltage
and continuity. Meg-ohm meter capable of checking up to 500 megohms of resistance to properly check ground loop integrity.
A malfunction can be isolated to one of the following:
• Gate Operator
• Loop System
• Keying Devices.
Disconnect all external inputs to the circuit board.
1.
Check the input indicator LED’s. They should only come ON when a keying device (card reader, push button, etc.) is
activated. If any of the input LED’s are ON continuously, this will cause the gate operator to hold open. Disconnect the keying
devices one at a time until the LED goes OFF (see troubleshooting guide).
2. If the operator stops or holds open, check external secondary entrapment protection devices for any shorts or malfunction.
3. A malfunction in a loop or loop detector can cause the gate operator to hold open, or not detect a vehicle when it is present
over the loop. Pull the loop detector circuit boards from the loop ports on the operator circuit board. If the malfunction persists,
the problem is not with the loop system. For more information refer to the loop detector instruction sheet and the DoorKing
Loop and Loop Detector Information Manual.
4. Check that there are no shorted or open control wires from the keying devices to the gate operator. If a keying device fails
to open the gate, momentarily jumper across terminals 1 and 2 on the control board. If the gate operator starts, this indicates
that a problem exist with the keying device and not with the gate operator.
5. Check the supply voltage and batteries. A voltage drop on the supply line (usually caused by using too small supply voltage
wires) will cause the operator to malfunction. Batteries should be fully charged for proper operation, replace batteries every two
years on average.
