Page 16
14
6002-065-M-6-08
2.1 Wiring Actuator Arm
(
s
)
SECTION 2 - WIRING
Before attempting to connect any wiring to the control box, be sure that the circuit breaker in the electrical panel is in the OFF
position. Permanent wiring must be installed to the control box as required by local electrical codes. It is recommended that a
licensed electrical contractor perform this work.
Since building codes vary from city to city, we highly recommend that you check with your local building department prior
to installing any permanent wiring to be sure that all wiring to the control box (both high and low voltage) complies with
local code requirements.
THIS GATE OPERATOR MUST BE PROPERLY GROUNDED!!
Primary
Actuator
Cable
Secondary
Actuator
Cable
1
7
6
5
4
3
2
1
2
3
4
5
6
7 8
9 10 11 12 13 14 15 16 17 18 19 20
Brown
Blue
Orange
Red
Yellow
Green
Green/Yellow
Not Used
Secondar
y Actuator Cable
Primary or Secondary Cable Connection
Primar
y Actuator Cable
1
7
8
6
5
4
3
2
DoorKing interconnection cable (P/N 2600-75x)
1
7
6
5
4
3
2
