24
6002-065-M-6-08
4.1 Maintenance
4.2 Troubleshooting
SECTION 4 - MAINTENANCE AND TROUBLESHOOTING
When servicing the gate operator, always check any secondary (external) reversing devices (loops, photo eyes, etc.) for proper
operation. If external reversing devices cannot be made operable, do not place this operator in service until the malfunction can
be identified and corrected.
Always check the inherent reversing system when performing any maintenance. If the inherent reversing system cannot be
made operable, remove this operator from service until the cause of the malfunction is identified and corrected. Keeping
this operator in service when the inherent reversing system is malfunctioning creates a hazard for persons which can result
in serious injury or death should they become entrapped in the gate.
When servicing the gate operator, be sure that the 24 VAC input power and batteries are disconnected.
Inspection and service of this gate operator by a qualified technician should be performed anytime a malfunction is observed or
suspected. High cycle usage may require more frequent service checks.
Operator
Component
Maintenance
Monthly Interval
6 3 12
Alarm
Batteries
✓ ✓
✓ ✓
✓ ✓
✓
✓ ✓
✓
✓
✓
✓
✓
✓
✓
✓
Fire Dept.
Gate
Loop(s)
Release
Primary Reverse System
Secondary Reverse Device
Complete System
Activate the primary (inherent) reverse system by blocking the
gate with a solid object. When the gate reverses, block the gate
in the opposite direction prior to the limit being reached. The
entrapment alarm should activate. Press the reset button to
silence the alarm.
Check the batteries for any leakage or loose connections.
Batteries should be replaced every two years.
Check vehicular reverse and shadow loops for proper operation.
Check manual release for proper operation.
Complete check of gate and gate operating system.
Check emergency vehicle access device for proper operation.
Inspect for damage. Check gate hinges for wear and grease if
necessary.
Check that the gate reverses on contact with an object in both
the opening and closing cycles.
Adjust the reversing sensor if necessary.
Check secondary (external) reverse device(s) stop or reverse the
gate when activated.
Symptom Possible Solution(s)
• Check that AC power to the operator is turned ON.
• Check battery power.
• Check for 24 VAC at terminals 19 and 20. If voltage measures OK, check the terminal strip or
replace the circuit board.
Actuator(s) will not
run. Power LED is
OFF.
