E - 1
APPENDIX E: MONITOR PARAMETER
REFERENCE
CODE DESCRIPTION MIN MAX UNITS
MP-40 Tach 0 9999 ENG.
MP-41 Lead Frequency 0 9999 HZ
MP-43 Feedback Frequency 0 9999 HZ
MP-44 Deviation (Error) 0 9999 HZ
MP-45 Scaled Reference 0 9999 HZ
MP-46 Ramped Reference 0 9999 HZ
MP-47 Drive Output 0 +100 %
MP-48 Trim Output -4095 4095 DAC bits
MP-49 PIDF Output 0 4095 DAC bits
MP-50 Active Scaling Mode 0 1100 CODED
MP-51 Keypad Error 0 1000 CODED
MP-52 Alarm Status 0 1110 CODED
MP-53 Control State 0 1000 CODED
MP-54 Logic Inputs - Group A 0 1111 CODED
MP-55 Logic Inputs - Group B 0 0011 CODED
MP-56 Logic Outputs 0 0011 CODED
MP-57 EEPROM Status 0 1 CODED
MP-58 Serial Comm Error 0 1111 CODED
MP-59 Frequency Overflow Counter 0 9999 COUNTS
MP-82 Motor Current 0 15.0 AMPS
MP-83 Current Limit Status 0 1 CODED
MP-99 Software Code Revision — — —
