Operation
90
SIPART PS2 Manual
A5E00074631-01
4.5 Diagnosis
4.5.1 Diagnostic display
You go to the diagnostic display from automatic or manual operation by
simultaneously pressing all three keys for at least two seconds.
Table 3-1, page 91 shows an overview of the displayable values. In the
third column the corresponding English term from which the abbrevia-
tion is derived is shown next to the German meaning unless this is self
explanatory.
The diagnostic display has a similar structure to in the ”Configuration”
operating mode. the top line shows the value of the diagnostic variable,
the bottom line the number and abbreviation of the displayed variable.
The respective next diagnostic value can be selected with the operation
mode key
. By pressing and holding the operation mode key and
additionally pressing the decrement key you can select the diagno-
stic values in reverse order.
Certain values can be set to zero by pressing the increment key for
at least 5 seconds. This is noted in the last column in the table.
Some diagnostic values may be greater than 99999. In this case the
display switches to exponential display. Example: the value 1234567 is
displayed as 1.23E6.
No. Abbrevia-
tion
Meaning Displayable
values
Unit Rest
poss.
1 STRKS Number of strokes (Strokes) 0 to 4.29E9 -- x
2 CHDIR Changes of direction (Changes of Direction) 0 to 4.29E9 -- x
3 CNT Fault counter (Counter ) 0 to 4.29E9 -- x
4 A1CNT Alarm counter 1 (Alarm 1 Counter) 0 to 4.29E9 -- x
5 A2CNT Alarm counter 2 (Alarm 2 Counter) 0 to 4.29E9
6 HOURS Operating hours (Hours) 0 to 4.29E9 Hours
7 WAY Determined actuating path (Way) 0 to 130 mm or _
8 TUP Travel time up (Travel Time Up) 0 to 1000 s
9 TDOWN Travel time down (Travel Time Down) 0 to 1000 s
10 LEAK Leakage (Leakage) 0.0 to 100.0 %
11 P0 Potentiometer value below stop (0%) 0.0 to 100.0 %
12 P100 Potentiometer value bottom stop (100%) 0.0 to 100.0 %
13 IMPUP Impulse length up (Impulse Length Up) 2 to 100 ms
14 IMPDN Impulse length down (Impulse Length Down) 2 to 100 ms
15 DBUP Dead zone up (Dead Band Up) 0.1 to 100.0 %
16 DBDN Dead zone down (Dead Band Down) 0.1 to 100.0 %
17 SSUP Short step zone up (Short Step Zone Up) 0.1 to 100.0 %
18 SSDN Short step zone down (Short Step Zone Down) 0.1 to 100.0 %
19 TEMP Current temperature --40 to 85 _ C
20 TMIN Minimum temperature (”drag pointer”) --40 to 85 _ C
21 TMAX Maximum temperature (”drag pointer”) --40 to 85 _ C
22 T1 Number of operating hours in Temperature range 1 0 to 4.29E9 Hours
23 T2 Number of operating hours in Temperature range 2 0 to 4.29E9 Hours
24 T3 Number of operating hours in Temperature range 3 0 to 4.29E9 Hours
25 T4 Number of operating hours in Temperature range 4 0 to 4.29E9 Hours
26 T5 Number of operating hours in Temperature range 5 0 to 4.29E9 Hours
27 T6 Number of operating hours in Temperature range 6 0 to 4.29E9 Hours
