Introduction
14
SIPART PS2 Manual
A5E00074631-01
1
2
3
4
1 Actuator
2 Positioner, single action in metal housing
3 Lantern
4 Manometer block, single action
Figure 1-3 Explosion proof positioner mounted on linear actuator (single action)
1
2
3
1 Positioner double action in plastic housing
2 Rotary actuator
3 Manometer block, double action
Figure 1-4 Explosion proof positioner mounted on rotary actuator (double action)
