7.3 Service menu
The Table 5 shows the Service menu.
First level
Second level Description
Back Go Back to the PB-507 main menu
Calibration Function
generator Select Function generator to calibrate the
Function generator module
Pulse
generator Select Pulse generator to calibrate the Pulse
generator module
DC power
supplies Select DC power supplies to calibrate the DC
power supplies module
USB host
status Select USB host status to view the USB
connection status
Error log Select Error log to view the errors
Software info Select Software info to view the boot loader
and firmware version
Update
firmware Select Update firmware to perform a firmware
update
Table 5
8 CALIBRATION
This section gives a complete description of the calibration features of the PB-
507 Trainer. Three modules can be calibrated: Function generator, Pulse
generator and DC power supplies.
In order to perform the calibration procedure, the PB-507 Trainer must be
unsecured. If PB-507 is secured, the “Device secured. Unsecure first.” message
will appear on the display when you want to enter in calibration mode. To
unsecure the PB-507 Trainer, please refer to section “Security” in this manual.
8.1 Function generator calibration
Equipment used:
•
Oscilloscope with probe set to x10.
•
600 Ohm ± 1% termination.
The precision of the calibration depends on the precision of the oscilloscope
used.
To calibrate the Function generator module, 10 steps must be completed.
The following rules are applied:
