27


In the following table is summarized the factory default settings of the PB-507
Trainer:

Parameter

Factory setting

Function generator

Frequency

1.000 KHz

Level

1.0 Vpp

Waveform

Sine

Output On/Off

Off

TTL On/Off

Off

Pulse generator

Frequency

1.000 KHz

Level

1.0 V

Duty cycle

50 %

CMOS On/Off

Off

TTL On/Off

Off

Frequency counter

Input signal type

Bipolar

Counter mode

Automatic

DC power supplies

Positive voltage

1.0 V

Negative voltage

- 1.0 V

Logic switches

8 logic switches state

Logic Low

Logic family

TTL

SPDT switches

SPDT1

State 1

SPDT2

State 1

Logic indicators

Logic family

TTL

Logic probe

Logic family

TTL

Operation mode

PULSE

System-related settings

Contrast adjustment

59%

Video mode

Normal

Automatic save

On

Power on

Default

Front panel keys

Unlocked

Page scrolling

Manual

Panel displayed after power-on

Function Generator

Security

Secured

Table 3
