remote flow rate controller 8032
General features
Medium data depends on the measuring device
Measuring range depends on the measuring device
Repeatability 0�4% of measured value
Protection rating
- wall-mounted version
IP 65, with cable plugs plugged-in and tightened
- panel-mounted version IP 54, for the front plate
IP 20, for the rear side, inside the cabinet
Panel thickness
(panel-mounted version)
min� 1 mm, max� 3 mm
electrical features
Installation class
(overvoltage class)
2
Insulating strength 2300 VAC
Power supply 12-30 VDC, depends on the measuring device data as well
3 technical data
remote sensor supply voltage
8041 18-30 VDC
8020 12-30 VDC
8030 12-30 VDC
other min� 12 VDC
max� 30 VDC
