45

Accessories/Spareparts

Type 8710, 8711, 8713, 8715

types

item

order code

Profibus

versions of

types 8700,

8701, 8710

and 8711

GSD sheet

Download from

www.burkert.

com

DeviceNet,

CANopen

version of

types 8700,

8701, 8710

and 8711

Straight M12 plug (code A)

917 115

Straight M12 socket (coupling)

(code A)

917 116

DVN/CAN* Y-piece

788 643

DVN/CAN terminal resistor

(code A)

On request

EDS sheet for DeviceNet

Download from

www.burkert.

com

8703, 8705,

8713, 8715

SUB-D 9-pin base

(to be soldered)

917 623

RS232 adapter for connection to

a PC

667 530

Extension cable for Sub-D 9-pin

plug, RS232, 2 m

917 039

USB adapter

670 693

Sub-D 9-pin adapter with

2 terminal blocks (for 2 connection

cables)

919 465

* The two previous M12 connectors cannot be used together on the same

side of the Y-junction. At least one of the two M12 connectors must be a

prefabricated cable with a thinner connector.

10.1.2. fluid accessories

The MFM / MFC are equipped with a connection plate which uses
a DIN ISO 228/1 thread process connection.
A threaded fitting available as an accessory is used to connect
the device to a line:
• the connection to the device side has a DIN ISO 228/1 thread,
• the connection to the line side is available in a range of

dimensions.

A sealing ring must be ordered for each screw fitting!

connection
to the device,
with Din iso
228/1 thread

Diameter of
the line

material

order code order code,

sealing ring

G 1/4

6 mm

Stainless
steel

901 538

901 575

G 1/4

8 mm

901 540

901 575

G 1/4

1/4 "

901 551

901 579

G 1/4

3/8 "

901 553

901 579

Other accessories for the fluid connection of an
MFM / MFC can be found under Type 1013 in the Bürkert
accessories catalog.

English
