36

Operationandfunction

Type 8700, 8701, 8703, 8705

operating mode

status of the leDs
(default setting)

binary input activation mode

this operating mode may be interrupted
or ended by

Set-point
value profile
(see chap. 8.3.4)

Limit light (blue) flashing

Power / Autotune

Limit (y)

Error

Input active for at least 0.5 s (permanent
input activation leads to a function restart)

• Function

Autotune

• Safety function
• Device reset

Control mode
(see chap. 8.3.5)

Limit light (blue) flashing

Power / Autotune

Limit (y)

Error

As long as the input is active

• Function

Autotune

• Safety function
• Device reset

Table 5: Overview of the operating modes.
