26
Technical Data
Outputs:
Actual value: Standard signal 0/4 – 20 mA
max. burden: 600 Ω
Resolution: 20 µA
Standard signal 0 – 5/10 V
max. current: 10 mA
Resolution: 10 mV
Binary output: potential-free changers 60 V, 1 A, 60 VA (assignment can be configured)
8709 and 8719: 2 binary outputs
8708 and 8718: 1 binary output
Display:
Light-emitting diodes: Status display for Power, Communication, Limit, Error (assignment
can be configured)
8709 and 8719: 4 LEDs
8708 and 8718: 3 LEDs
Field buses: alternative to the standard signal version
PROFIBUS DP V1
DeviceNet
CANopen
Electrical connections: 8719 and 8709:
8-pole round socket
15-pole Sub-HD socket
optional: 5-pole M12 socket or plug for field bus
8718 and 8708:
15-pole Sub-D plug
optional: 5-pole M12 socket or plug for field bus
english
Type 8718, 8719 / 8708, 8709
