TechnicalData
6.5.3. electronic base module me02, me03 / 2-fold bistable
technical data me02 / 2-fold
bistable
me03 / 2-fold
bistable
Dimensions WxHxD 22 x 70.5 x 52 mm 33 x 93 x 60 mm
Weight 35 g 44 g
Storage temperature -20 ... +60° C -20 ... +60° C
Nominal load voltage DC 24 V DC 24 V
Number of valve outputs 2 2
Power consumption per valve location 41 mA 41 mA
Power consumption from the backplane bus max. 10 mA max. 10 mA
Display of the valve status 2 yellow LED per valve
location
2 yellow LED per valve
location
Power loss of the module (Type 0460) 1.8 W -
Power loss of the module (Type 0461) - 1.8 W
