Configuring the network
Abbreviations:
storage (requested storage class)
n
Non-volatile parameter which must be observed in the operating cycle. However, it does
not belong to the static updating code.
s
Static, non-volatile; the version counter ST_REV is increased during the write process.
D (dynamic)
The value is calculated in the block or read from another block.
Cst (constant)
The parameter does not change.
access
r
read access
w
write access
The standard parameter View Object
rel. index Variable
View_1
View_2
View_3
View_4
1
ST-REV
2
2
TAG_DESCRIPTION
3
STRATEGY
4
ALERT_KEY
5
TARGET_MODUS
6
MODUS_BLK
3
7
ALARM_SUM
8
View Object of the standard parameters
Table 3:
Mode structure
This data structure consists of character strings for current, set and normal modes.
Data type:
Mode
Key attributes:
Index = 37
Indicator:
Number of the elements
Indicator:
List of the elements
E
name of the element
Data type (index)
size (byte)
1
current
Unsigned 8 - (5)
1
2
permitted
Unsigned 8 - (5)
1
3
normal
Unsigned 8 - (5)
1
List of the elements of the mode structure
Table 4:
