Burkert Type 0258 - Manual (Page 11)

0258 - 9
english
Basic module
You can use all basic modules individually or in a block.
Filter module
Description
The filter module can be shut off by
hand. Note the direction of flow.
As an option, the filter module can be
fitted with a magnetic insert.
Block symbol
manual lever
4 2
2-way flow valve
Description
The 2-way flow valve is continuously
operated.
The direction of flow:
P
A, P B
Block symbol
4 2
1
3
