C-4-2 Channel Input Port Commands
C-4-2-1 Measured Channel Values Command
This command is used to gather measured information from one or all
channel input ports. Protocol responses are compatible with existing
published protocol formats. Frames noted below as lower case 'x' remain
, regardless of frame content.
HOST SEND
Non-Networked
AZ[.xx]K Send one channel input port values
Networked
AZ[yyyyy.xx]K Send one channel input port values
RESPONSE - ONE CHANNEL INPUT PORT MESSAGE
AZ,00909.01,2,xxxxxxxx.xx,00162871.43,-0000003.27,xxxxxxx.xx,xxxxx,X,X,X,X,X,
Explanation of response values above
Parameter
Number
Value in
Example
Description
1 AZ response pre delimiter
4 2 response type
5 xxxxxxxx .xx Non resettable totalizer value
6 00162871.43 T otalizer value
7 0000003.27 proces s value
… reserved parameters
15 c heck sum
16 c arriage return character
17 line feed character
00909
01
network address of 0254
Read Out device
port number
(input port channel 1)
2
3
