2
INSTALLATION
This section contains information that you need to prepare the HP 100/200LX
for ThinFax 1414-LX/LXM, including how to insert and remove the card and how to
test the modem's installation with DataComm.
Note1: To prolong the HP 100/200LX's battery life, Hewlett-Packard
recommends the following procedure should be observed:
If possible use an AC Adapter whenever the ThinFax modem card is
plugged into the HP 100/200LX.
Note2: A reminder for ThinFax LXM user, the FLASH memory portion of the
card will consume power from the palmtop when the card is inserted and
the power switch is set to ON.
Keystrokes Convention
Sometimes you may need to press the keyboard in series or combination
keystrokes. The following are the keystrokes convention used in this guide:
Sequential key: MENU, F, S Press the keys shown in sequence.
(without , )
Hot-key: Alt + F2 Press and hold down the key(s) shown then
tap the last key. The last key can be any underline letter
(DataComm) displayed on the screen or a Function key.
SYSTEM REQUIREMENT
Preparing the HP 100/200LX
Memory: You should reserve at least 400 KB of system memory for the MiniFax
(70KB) and the HP System Manager. If you plan to use other built-in
applications, consider increasing the size of the system memory
accordingly. Press the &… and S key to start Setup.
Hardware Installation
Note: HP does not recommend performing the insertion/removal of the
PCMCIA card into/from the HP 100/200LX when its power is on. Turn
the power to the computer OFF before attempting the following
operation. This card is also sensitive to static electricity.
System RAM Memory
Need at least 400K
