1
INTRODUCTION
Thank you and welcome to our next generation of the ThinFax modem card for
HP 100/200LX. This User's Manual explains in detail how to install, and how to
operate the ThinFax modem cards. The following products are covered in this manual:
ThinFax 1414LX (Modem + MiniFax)
ThinFax 1414LXM (Modem + MiniFax +
2, 4 or 8 MB FLASH memory)
Both ThinFax cards come with MiniFax, an onboard fax program with the same user
interface of the HP 100/200LX palmtop computer. The MiniFax is a full function fax
program, which user can send, receive, view and print fax documents.
The ThinFax 1414LXM (Modem + Memory Combo card) has all the functions and
features of the ThinFax 1414LX plus 2, 4 or 8 MB Flash Memory within the card setup
as the F: drive. (typical)
ThinFax 1414-LX/LXM can be used as Fax/Data modem on any PC Card
(PCMCIA 2.10) compatible computers as well. Users must install a PC Card
(PCMCIA 2.10) device driver(s) with a DOS-Based or WINDOWS-Based software to
utilize Fax/Data function.
FEATURES
‘ ‘ Low power consumption
‘ ‘ 2 MB, 4MB or 8 MB low power (5V) FLASH memory
(ThinFax 1414LXM Only)
‘ ‘ PC Card (PCMCIA 2.10) Type II Card size, 54.0 mm x 85.6 mm x 5.0
mm
‘ ‘ Data speed up to 14,400 bps.
‘ ‘ Data mode protocols:
CCITT V.32bis, V.32, V.22bis, V.22, and V.21
Bell 103 and 212A
‘ Error correction: V.42, MNP 2-4
‘ Data compression: V.42bis, MNP5
‘ Send and receive Fax speed up to 14,400 bps.
‘ ‘ Fax mode protocols:
CCITT
V.17, V.29, V.27ter, and V.21 Ch. 2
EIA/TIA 578 Class 1
Fax Group III compatible.
‘ ‘ Automatic power save mode
‘ ‘ MiniFax:
Resides in the card.
Log of Send/Receive fax
Previewing a fax on the screen before sending.
Viewing received faxes.
Fax Telephone Directory via the HP 100/200LX Phone Book application
User-friendly interface
Fax cover page
Multiple printer support
