Operation Manual of P T Z Dome Camera
8
2.3 Dome information
Joystick down to move the cursor to press OPEN or joystick left or right to move the
joystick to enter the menu.
2.4 Display Options
Set the display of dome info or function.
4. Control Options
Set the pan or tilt and camera of the dome manually or auto compatible with the entire
control system. User individualized operation setting.
5.Camera Options
Set camera function.
6. Function Programming
Program and execute PTZ and VectorScan etc.
7. SYSTEM SETUP
System setup, Including, restore default setup clear memory, color system,
dome reset.
TITLE
CAMERA : xxxx
PROTOCOL : xxxx
BAUDRATE : xxxx
DOME ID : xxx
VERSION : xxx
IRIS CLOSE TO EXIT
TITLE
The title may be different with different type
of dome.
Display camera type\ protocol\
baundrate\dome ID\ software version
Operation steps
[1].Joystick up/down to move the cursor to
select Display Options
[2].Joystick left/right to enter Display Option
[3].Joystick up/down to select either one of the
sub-menu
[4].Joystick left/right to select ON/OFF
DISPLAY OPTIONS
1 CAMERA NAME SETUP
2 COORDINATES ON
3 START_UP SCR MSG ON
4 CROSSHAIRS ON
