Operation Manual of P T Z Dome Camera

[3].Joystick Up/Down to select pending

operating

programming

Pattern(number range:1～3).

[4].Joystick Up/Down to move the cursor

to select Program a Pattern.

[5].Press OPEN to enter recording of the

manual running trace.as left Fig 1.

[6].Press CLOSE to finalize the

selection. as left Fig 2.

[7].Joystick Up/Down to move the cursor

to select NAME.

[8].Edit name (Please refer to name

setting section of preset position)

PATTERN

1 NUMBER 1
2 PROGRAM A PATTERN
3 RUN A PATTERN
4 DELETE A PATTERN
5 NAME ______
6 NAME DISPLAY OFF

IRIS OPEN TO BEGIN

IRIS CLOSE WHEN DONE

Fig 1

Fig 2

[9]. Joystick Up/Down to move the cursor to select Name Display.

RUN A PATTERN

Running Pattern Tracking Operation Steps:
[1].Select pending running Pattern trace from NUMBER.
[2].Joystick Up/Down to select Run a Pattern.
[3].Joystick Left/Right or press OPEN to run the trace of selected Pattern.

DELETE A PATTERN

Delete Pattern Operation Steps:
[1].Select pending Delete Pattern trace from NUMBER.
[2].Joystick Up/Down to select Delete a Pattern.
[3].Joystick Left/Right or press OPEN to enter and Click OPEN to delete

the trace of selected Pattern as below Fig 3～Fig 4
