2.7.3 Pattern
Function: User can program three traces simulating manual operation.
I
:Name
Pr:stands for Preset Position.
Vs:stands for VectorScan.
Pt: stands for PTZ Tour.
II
:Number Programming-selection
based on the name.
III
:SP-Set up the speed of Preset.
IV
:Dwell
Vectorscan running operation steps:
I
:Select pending Vectorscan track in
Number menu
II
:Joystick Up/Down to select Vectorscan
III
:Joystick Left/Right or press OPEN to
run the selected Vectorscan track
VECTORSCAN
1 NUMBER 1
2 PROGRAM A VECTORSCAN
3 RUN A VECTORSCAN
4 DELETE A VECTORSCAN
PROGRAM VECTORSCAN 1
NAME NUM SP DWELL
1.
2.
3.
4.
... ...
16.
IRIS CLOSE WHEN DONE
DELETE A VECTORSCAN
Vectorscan track deletion steps:
[1]:Select pending deleting vectorscan track in Number menu.
[2]:Joystick Up/Down to select Delete a VectorScan.
[3]:Joystick Left/Right or press OPEN to delete the selected vectorscan track.
FUNCTION PROGRAMMING
1 PRESET
2 VECTORSCAN
3 PATTERN
4 SECTOR SETUP
5 MASK ZONE
6 MASK COLOR
7 MOTION
PATTERN
Pattern Operation Steps:
[1].Joystick Up/Down to move the
cursor to select Pattern.
[2].Joystick Left/Right or press OPEN
to enter the menu.
