Operation Manual of P T Z Dome Camera

2.7 Function Programming

2.7.1 Preset

1.Number

[1].Move the joystick left/right or press OPEN to enter the number editing programming.

PS: Program the number of preset position.

[2].Move the joystick left/right to select the number editing (numeral line 0~9),press

OPEN to confirm the selection. Press CLOSE to exit when your selection done.

2.Set Preset

[1].Move the cursor to select preset position.

[2].Move the joystick left/right or OPEN to enter the setting(ensure the preset position

data you desire to save)

[3].Press OPEN to finalize your selection, then the screen displays STORED and

return to the previous menu level. Or press CLOSE to return to the previous menu

FUNCTION PROGRAMMING
1 PRESET
2 VECTORSCAN
3 PATTERN

4 SECTOR SETUP
5 MASK ZONE
6 MASK COLOR
7 MOTION

Preset option

1. Move the joystick left/right or press

OPEN to enter Function Programming
options.

2. Move the joystick up/down to move the

cursor to select the preset options.

3. Move the joystick Left/Right or press

OPEN to enter preset options.

PRESET

1 NUMBER 1
2 SET PRESET
3 CALL PRESET
4 DELETE PRESET
5 NAME ____________
6 NAME DISPLAY OFF

INPUT RANGE:

1~50 64~77 102~165

0 0 1

0 1 2 3 4 5 6 7 8 9

IRIS CLOSE WHEN DONE
