Operation Manual of P T Z Dome Camera
16
5. Name
6. NameDisplay
2.7.2 Program VectorScan
Function: User can make different auto scan according to various inspection.
NameDisplay
Setup On/Off display on the direction
name preset.
[1].Move the cursor to select name
display.
[2].Move the joystick left/right to set ON
or OFF of the name display.
PRESET
1 NUMBER 1
2 SET PRESET
3 CALL PRESET
4 DELETE PRESET
5 NAME ____________
6 NAME DISPLAY OFF
PRESET
1 NUMBER 1
2 SET PRESET
3 CALL PRESET
4 DELETE PRESET
5 NAME _____________
6 NAME DISPLAY OFF
Name
[1].Move the joystick up/down to move the
cursor to select the Name.
[2].Move the joystick left/right or press
OPEN to enter name editing menu.
(Please refer to name setting section of
Camera Name Setup)
Programming VectorScan instruction
[1].Joystick Up/Down to select Program
VectorScan.
[2].Joystick Left/Right or press OPEN to
enter the programming.
[3].Joystick Up/Down to select pending
programming serial number(number
range:1～6).
[4].Move the Joystick to select and enter
the items of Program a VectorScan
(items include:name/number/SP/dwell).
FUNCTION PROGRAMMING
1 PRESET
2 VECTORSCAN
3 PATTERN
4 SECTOR SETUP
5 MASK ZONE
6 MASK COLOR
7 MOTION
