Operation Manual of P T Z Dome Camera
9
2.4.1 Camera Name Setup
Set the camera name
2.5 Control Options
Set Auto Flip、Auto Focus、Auto AE, etc Move the joystick left/right or press
OPEN to enter control options
2.5.1 Dome Addr Setup
CAMERA NAME SETUP
1 NAME ___________
2 NAME DISPLAY OFF
PLEASE ENTER:
WELCOME_________
ABCDEFGHIJKLN
OPQRSTUVWXYZ
0123456789_
IRIS OPEN WHEN DONE
IRIS CLOSE TO EXIT
1.NAME
[1].Move the joystick up/down to move the
cursor to select the Name.
[2].Move the joystick left/right or press OPEN
to enter name editing menu.
[3].Joystick left/right to select programming
position and press OPEN to confirm,
joystick left/right again to select( 0~9 or
A~Z ). Press OPEN to confirm selection.
Press CLOSE to exit or return to the
previous menu level when programming is
done.
6 VECTORSCAN STILL OFF
7 AUTO FOCUS OFF
8 AUTO AE OFF
9 VECTORSCAN AF OFF
10 -2 TILT LIMIT OFF
11 SPEED LIMIT OFF CONTROL OPTIONS
1 DOME ADDR STETUP
2 AUTO FLIP ON
3 PROPORTIONAL SPD ON
4 PAN REVERSE OFF
5 TILT REVERSE OFF
1. Joystick left/right to setup the addr type.
addr type through Physic/Logic.
2.Joystick left/right to change the dome ID(only
when addr type selects logic).
3.Joystick left/right to setup the broadcast ID
ON/OFF.
DOME ADDR SETUP
1 ADDR TYPE PHYSIC
2 DOME ID 1
3 BROADCAST ID OFF
