ENGLISH
1.
Open rear tailgate and locate the
vehicle jack storage compartment on
the Driver’s side. Remove panel and
tire jack to access harness area.
de
2. Locate the to
w vehicle’s trailer harness
connector. This harness is located in
the inside of the Driver’s side tire jack
compartment.
f
3. Locate the 6-pin connector
, which is
taped to the vehicle wiring harness.
This is located at the floor of the tire
jack compartment.
g
4. Remo
ve the tape on the vehicle’s plug
and insert the T-Connector into the
vehicle’s trailer plug harness. Be sure
that the T-Connector is fully inserted
with locking tabs in place.
5. Locate a suitab
le grounding point near
the connector such as the vehicle's
frame or cross member. (Do not drill
into vehicle floor or bed.) Clean dirt
and rustproofing from area. Drill a
3/32" hole and secure
white wire
using eyelet and screw provided.
CA
UTION
V
erify what is behind any surface
prior to drilling to avoid damage to
the vehicle and/or personal injury.
Do not drill into any exposed surfaces.
W
ARNING
All connections m
ust be complete for
the T-Connector to function properly.
Test and verify installation with a test
light or trailer once installed.
NO
TE:
Store 4-flat in jac
k storage
compartment when not is use.
W
ARNING
Ov
erloading circuit can cause fires.
DO NOT exceed lower of towing
manufacturer rating or:
• Max. stop/turn light: 1 per side
(2.1 amps)
• Max. tail lights: (5 amps)
Read vehicle’s owners manual
and instruction sheet for
additional information.
Installation Instr
uctions
Directives de Montage
Instrucciones de Instalación
T-Connector
Connecteur en T
Conector en T
18391-037
Rev. A
11/07/04
READ
THIS FIRST:
Read and f
ollow all instructions carefully
before beginning installation.
LISEZ CECI EN PREMIER:
Lire et suivre toutes les instr
uctions
attenrivement avant le montage.
LEA
ESTO PRIMERO:
Lea y siga todas las instr
ucciones cuidadosa-
mente antes de iniciar la instalación.
