Draw-Tite 118248 OEM WIRING HARNESS User Manual
Draw-Tite For the car

ENGLISH
TOOLS NEEDED:
13mm Soc
ket & Ratchet or
13mm Wrench, Test-probe
1. Open the v
ehicle’s rear tailgate. On the
driver's side, remove access panels,
threshold, trunk floor panels and trays
de
.
Set aside all items removed being
careful not to damage parts.
2. On the dr
iver's side, locate the vehicle's
factory tow harness connector. Separate
these connectors, being careful not to
break the locking tabs. Check to see that
the mating surfaces of the vehicle harness
connectors match the Tow-Plug Adapter
ends. All connector surfaces should be
clean and free of dirt.
3. Inser
t the Tow-Plug Adapter and
lock into place
f
.
Be careful not to
damage the locking tabs and be sure
that connectors are fully inserted with
locking tabs in place.
4. Locate the e
xisting ground stud. Loosen
bolt, place screw eyelet on stud and
re-tighten bolt
g
.
5. Consulting y
our owner's manual, locate
the Towing Fuse location and insert the
10A fuse (provided).
18248-037
Rev. A
07/30/04
Installation Instr
uctions
Directives de Montage
Instrucciones de Instalación
Tow-Plug Adapter
Adaptateur de Fiche de Remorque
Adaptador Para Remolque
READ
THIS FIRST:
Read and f
ollow all instructions carefully
before beginning installation.
LISEZ CECI EN PREMIER:
Lire et suivre toutes les instr
uctions
attenrivement avant le montage.
LEA
ESTO PRIMERO:
Lea y siga todas las instr
ucciones cuidadosa-
mente antes de iniciar la instalación.
W
ARNING
All connections m
ust be complete for the
Tow-Plug Adapter to function properly. Test
and verify installation with a test light or
trailer once installed.
6. On the dr
iver's side, mount the
b
lack
bo
x using the double-sided tape provided.
Secure the remainder of the harness with
the cable ties provided
h
.
To prevent
damage or rattling, be careful to avoid
any areas that would cut or pinch the wire.
7. Reposition the tr
ays, trunk floor panels and
access panels and reattach the threshold.
NO
TE
Store 4-Flat in tr
unk or rear cargo area
when not in use.
W
ARNING
Ov
erloading circuit can cause fires. DO
NOT exceed lower of towing manufacturer
rating or:
• Max. stop/turn light: 1 per side (2.1 amps)
• Max. tail lights: (5 amps)
Read vehicle's owners manual &
instruction sheet for additional information.
•
d
•
e
•
g
•
f
•
h
