10 Appendix
10.1 Type designation / ordering code
Description Type Key
MHM5 MHK5 DP C1 B - _ _ _ _ - _ _ _ _ - _ _ _
Interface Profibus DP
Version C1
Code Binary B
Singleturn 00
Multiturn (4,096 revolutions) 12
Revolutions (Bits)
Multiturn (16,384 revolutions) 14
4,096 (0.09°) 12
8,192 (0.04°) 13
Steps per revolution
(Bits)
65,536 (0.005°) 16
Clamp Flange, Full Shaft,  10 mm
C10
Synchro Flange, Full Shaft,  6 mm
S06
Synchro Flange, Full Shaft,  10 mm S10
Flange / Shaft Diameter
Blind Hollow Shaft,  15 mm
B15
Without 0
Shaft sealing (IP66) S
Mechanical options
Stainless steel version * V
Customized C
H3P
H2M
H3B
HCC
Connection With connection cap AH58-B1DP-3PG
With connection cap AH58-B1DP-2M20
With connection cap AH58-B1DP-072 (3x M12 Anschluss)
Without connection cap **
Standard = bold , further models on request
