It is possible to store up to 7 frames in the OPS200 non volatile
memory. Frames are mainly used as backgrounds in a typical
show or event setup, and can be recorded from any of the OPS200
11 sources and called back at the press of a single button.
* NOTE * : Frames may be used only one at a time and cannot be
placed in a layer.
1/ In the Input Selection section, press the source button (#1 to #11)
of the source you wish to record as a frame. The source button
will start blinking. Press the [TAKE] button to display that source
on the main display.
2/ Select Logos/Frames in the menu by rotating the scroll knob, then
pressing the [ENTER] button.
3/ Select Record Frames in the Logo/Frames menu by rotating the
scroll knob, then pressing the [ENTER] button. A white rectangle
will appear on your main display, indicating the frame which will
be captured. Select an empty frame memory (empty frames
are indicated in the sub-menu) to store the frame into. Press the
corresponding [ENTER] button.
4/ The OPS200 will display a progress status bar on the VFD
screen. Your frame is stored when the menu reappears on the
VFD screen.
5/ Press the [BACKGROUND FRAME] button, select the frame
number (#1 to #7) you just recorded, and press the [TAKE] button.
Your background frame will appear on your preview output.
+
Working with Frames
Memorizing Frames
Working with logos
It is possible to store up to 7 logos in the OPS200 non volatile
memory. Logos work in much the same way as frames, and can be
recorded from any of the OPS200 11 sources. Logos have many
more attributes than frames. They can be sized, positionned, but
also keyed via color cutout selection or luma key.
