PHYSICAL
Dimensions: W 482 x D 330 x H 88 mm
19”W x 13”D x 3.5”H.
(Compatible with a Standard 19” rack, Height = 2U).
Weight: 5 kg / 11 lbs.
ENVIRONMENTAL
Cooling air flow from right side to left side.
Maximum ambient operating temperature : < 40°C ( < 104°F).
Operating temperature: 0 to +40°C / +32° to +104°F.
Storage temperature: -40 to +70°C / -40° to +158 °F.
Operating humidity: 10 to 80% (non condensing).
Input voltage range: 100-240 VAC, 50/60 Hz.
Typical consumption: 90 W.
CERTIFICATIONS
CE Compliancy: test following
- EN 55022: 2006 / A1: 2007,
- EN 55024: 1998 / A1: 2001 / A2: 2003,
- EN 61000-3-2: 2006
- EN 61000-3-3: 1995 / A1: 2001 / A2: 2005,
Safety test following:
- IEC 60950-1: 2005
- UL 60950-1: 2007
- CAN/CSA-C22.2 NO. 60950-1
Power supply: IEC/EN/UL/CSA 60950-1, internal, autoswitchable
Mecanical (in carton): Vibration: IEC60068-2-64
Free fall : IEC60068-2-32, RoHS, WEEE
Environmental specifications
