8. To enable the Profile reset test function, press the key, on the front panel. The
proper voltage selected should be metered on the front panel display.
9. To run the Profile reset test function press and to trigger the test to run.
Please be aware this test does run for 340 seconds (See profile reset test figure above).
Starting profile
There are different profiles available for 12 V systems and 24 V systems, please refer to the
tables above to configure the power supply options properly.
Follow the steps below to set up the ISO16750-2 for Starting profile function:
1. Access the main menu by pressing and the .
2. Use the key to select FUNC. and press .
3. Use the key to select ISO16750-2 and press . The screen below will display:
4. While Short voltage drop is flashing, use keys to toggle to Starting profile (shown
below) and press to access that option.
5. Set to 12V for the 12V test system and 24V for the 24V test system.
6. Use the key to select the profile of 1 / 2 / 3 / 4(12 V only) and use keys to
toggle between the four options.
7. Use the key to select Repeat and press . This option allows the user to repeat
the profile up to 100 times. Once a value is selected, press to confirm.
8. Use the key to select Delay and press . This option allows the user to delay the
repeated profile up to 100 seconds. Once a value is selected, press to confirm.
9. Use the key to select Off/On and use keys to toggle between the two options.
Choose On to be able to run the function.
ISO16750-2 profile
Starting profile
0.000V 0.000A
0.0W Profile for reset
Trig
