12
3 Front Panel Operation
3.1 Menu Options
All settings and parameters can be configured from the built-in menu system of the power
supply. To access the menu, press and press .
The menu system is divided into the following sections and organized as follows:
SYSTEM
Initialize Reset power supply settings to factory default values.
Power-On Configure power-on state.
Trigger Configure Trigger.
Memory Select memory location for save/recall instrument settings.
Buzzer Enable/Disable key sound.
Communication Select communication interface.
ReturnMeter Enables automatic delay to switch display from setting to
measured value (meter).
CONFIG
Load Enables dummy load to increase speed of voltage fall time.
Ext-Ctrl Configures external analog control.
Limit Configures voltage setting limits.
Online Configures series/parallel connection and master/slave mode.
LIST 1
Off
Recall Recall list file.
EditList Configure list operation.
EditSeq Configure sequence operation.
FUNC 2
LIST Setup the LIST operation
DIN40839 Configure a DIN40839 test
ISO16750-2 Configure a ISO16750-2 test
INFO Show model, firmware version, and serial number.
1 Available on models 9115/9115-AT and 9116 only
2 Available on model 9115-AT only (LIST mode can be found in the menu)
How to Access the Menu
Before using the instrument, it is important to be familiarized with its menu structure and learn
how to view or change settings and parameters. Follow the steps below to guide you in
selecting menu options.
