Rear Panel Overview

Rear Panel Description

Analog Control Interface

Output Terminal

Rear Cooling Fan

GPIB Interface

USB Interface

RS-232 Interface

AC Input Receptacle

Fuse Box

RS-485 Interface

Remote Sense Terminals


1

2

3

3

4

5

6

7

8

9

10

1

2

3

4

5

6

7

8

9

Figure 1.4 - Rear Panel for 9115/9115-AT/9116

10
